Application areas: Special vehicles, machinery manufacturing, engine manufacturing, good sealing performance. Used in working environments that require high torque – for example, agriculture, irrigation, drainage systems, sludge suction, etc., for medium to large reinforced hoses. Although they are difficult to handle, they have very high requirements for durability and safety under tough conditions. The bending radius of the bridge plate, the smooth transition between parts and clamps, and the smooth underside of the belt provide a good contact surface with the hose, achieving excellent sealing.
Product advantages: Strong fastening force, good sealing.
| Serialnumber | Part Name (Chinese & English) | W1 | W2 | W4 | W5 |
|---|---|---|---|---|---|
| 1 | 箍带 Hoop straps | 铁镀锌 Iron galvanized | 201/304 不锈钢 | 201/304 不锈钢 | 316 不锈钢 |
| 2 | 桥板 Bridge plate | 铁镀锌 Iron galvanized | 201/304 不锈钢 | 201/304 不锈钢 | 316 不锈钢 |
| 3 | 轴 axis | 铁镀锌 Iron galvanized | 铁镀锌 Iron galvanized | 201/304 不锈钢 | 316 不锈钢 |
| 4 | 套管 casing | 铁镀锌 Iron galvanized | 铁镀锌 Iron galvanized | 201/304 不锈钢 | 316 不锈钢 |
| 5 | 螺钉 screw | 铁镀锌 Iron galvanized | 铁镀锌 Iron galvanized | 201/304 不锈钢 | 316 不锈钢 |
The adjustment range can be freely chosen between 19-252mm.
The adjustable size is 3~12mm.
